UNIVERSAL AUDIO
Apollo x16D Heritage Series w/ DANTE
Apollo x16D Heritage Series w/ DANTE
Couldn't load pickup availability
Take UAD plug-ins from studio to stage.
Perfect for live sound venues or networked recording studios, Apollo x16D gives you elite-class Apollo X sound and realtime UAD plug-in processing over Thunderbolt and Dante. With Apollo x16D, you can mix and record live performances with over 200 UAD plug-ins from Neve, SSL, and Auto-Tune, plus classic LA-2A and 1176 compressors, and more.
Mix studio and live performances using award-winning UAD plug-ins in realtime over Dante
Use Plug-In Scenes to recall settings instantly, even in the middle of a performance
Turn any space with ethernet into a multi-room Apollo recording studio
Link up to four x16Ds for a 64-channel Dante system with network redundancy
Bring your best UAD plug-ins like Auto-Tune, Neve, and Lexicon from studio to stage
Choose between Essentials+ and Ultimate+ editions, adding up to 100+ UAD plug-ins worth thousands of dollars
Take Elite-Class Apollo X Sound on Stage
We built Apollo x16D for both live sound engineers and networked recording studios. With its 16 channels of Dante I/O, elite-class audio conversion, and HEXA core DSP processing — the world’s most powerful system for running UAD plug-ins in realtime — Apollo x16D seamlessly connects to your digital mixing console, putting over 200 UAD plug-ins right at your fingertips.
Work Fast & Never Lose Your Settings
With its powerful digital mixing engine giving you control over inputs, outputs, and plug-in routing — Apollo x16D makes it easy to build your mix and control entire effects chains in realtime. Then quickly recall your plug-in settings over MIDI, all without interrupting the performance.
Hundreds of Effects, One Rack Space
Apollo x16D comes in two editions, both delivering a generous suite of UAD plug-ins right out of the box. Build your mix with classic Teletronix LA-2A and 1176 compressors, Pultec EQs, and Neve channel strips to modern favorites from Auto-Tune, Avalon, and more.
-
See plug-ins included with Ultimate+
-
See plug-ins included with Essentials
Expand Your Studio Over Dante
Link up to four x16Ds to build a 64-channel Dante system with network redundancy. Or expand your current Thunderbolt Apollo studio over Dante — the most low-latency and scalable audio network available. This means that if you’ve been considering making the switch to a networked recording studio, or you simply want to grow to a multi-room setup, you don’t have to start from scratch.*
Mix Down to Surround
After the show, bring Apollo x16D back to the studio, where it becomes your all‑in‑one monitoring hub for mixing formats up to 9.1.6. This allows you to easily create 16‑channel immersive audio mixes of live sets or studio recordings for Dolby Atmos, Auro‑3D, Sony 360 Reality Audio, and others.
18 x 20 audio interface featuring Dante I/O (supports AES67 mode @ 48 kHz)
24-bit/192 kHz elite-class Apollo X D/A conversion
Stereo AES I/O for connection to professional digital outboard hardware
Includes up to 100+ UAD plug-ins with Ultimate+ or Essentials+ editions
Recall plug-in settings over MIDI, even in the middle of a performance
Onboard HEXA Core Processing for mixing with UAD plug-ins at near-zero latency
Compatible with Thunderbolt Apollo interfaces to expand systems over Dante*
Create 16-channel immersive audio mixes for Dolby Atmos, Auro-3D, Sony 360 Reality Audio, and others
ALT monitoring support in all monitor modes (2 x ALT mon for stereo, 1 x ALT mon for all)
Free industry-leading technical support from knowledgeable audio engineers
